Project Description

SQ compact air cylinder

CQ2 Series  SQ Series Compact pneumatic cylinder

CQ2 compact cylinder also called SQ compact cylinder is European type compact cylinder. There are through hole and both end female two fixing types. Male or female thread is optional on the piston rod .The bore size is from 12 mm to 100 mm. For the acting type we have double acting, double adjustable acting, single extend acting, single return acting etc.

Features:
·Front/rear covers machined by All-in CNC machine, high consistency and concentricity
·Japanese anti-dust seals, better sealing performance and dust protection
·Threaded connection between barrel and covers with glue, easy and stable
·Special air cushion design, less impact from piston to front/rear cover
·Caps positioning machine guarantees front and rear caps locate at same horizontal position, easier to install

Supply Chain:
·Japan or Taiwan area seal
·Germany Grease
·Strong aluminum material

CQ2B mini compact cylinder

CQ2B mini compact cylinder
