AF Series Compressed Air Filter
| Ensured pressure Resistance | 1.5MPa(15kgf/cm²) |
| Highest Working Pressure | 1.0MPa(10kgf/cm²) |
| Ambient and Fluid Temperature | 5-60℃ |
| * Filter Precision | 25 µm |
| Container Material | Polycarbonate |
| Protective Cover | AF1000-2000 (Not Available) AF3000-5000 (Available) |
Compressed Air Filter Manufacturer
A series air treatment units SMC type
| Model | Specifications | Accessories | Drain Function | Auto Drain Model | |||
| * Rated Flow （L/min） |
Port Size （G） |
Bowl Capacity CM³） |
Weight （kg） |
Bracket | |||
| AF1000-M5 | 110 | M5 | 4 | 0.07 | – | Manual Drain | |
| AF2000-01 | 750 | 1/8 | 15 | 0.19 | B240 | AF2000-01D | |
| AF2000-02 | 1/4 | AF2000-02D | |||||
| AF3000-02 | 1500 | 1/4 | 20 | 0.29 | B340 | a. Air Shut off Drain
b. Manual Drain |
AF3000-02D |
| AF3000-03 | 3/8 | AF3000-03D | |||||
| AF4000-03 | 4000 | 3/8 | 45 | 0.55 | B440 | AF4000-03D | |
| AF4000-04 | 1/2 | AF4000-04D | |||||
| AF4000-06 | 6000 | 3/4 | 45 | 0.58 | B540 | AF4000-06D | |
| AF5000-06 | 7000 | 3/4 | 130 | 1.08 | B640 | AF5000-06D | |
| AF5000-10 | 1 | AF5000-10D | |||||
