Push In Fittings Brass POM BSPT BSPT NPT
Pneumatic Air One Touch Push In Fittings, Push to Connect, Brass nickel plated, POM reinforced plastic, teflon thread coating, O ring optional. Easy to connect, widely used in the compressed air pipeline, perfect for PU, PE, PA Nylon Tube. A variety of models option, meet all the demands in different automation fields.
- Rapid installation, time-saving, easy to connect and disconnect.
- Flexible directions, perfect for compact space use.
- Teflon thread coating, great sealing performance.
- Nickel Plated brass, anti corrosion.
- O ring, teflon coating optional.
- Support vacuum condition.
Pressure Range: 0-10 bar, 1.0 MPa
Max Pressure: 15 bar
Applicable Tube: PU, PA(Nylon)
Metric Size Table
| MODELS | Tube Size | Thread Size | Descriptions |
| PC 04-M5 | 4mm | M5 | Male Straight 4mm M5 |
| PC 04-M6 | 4mm | M6 | Male Straight 4mm M6 |
| PC 04-01 | 4mm | R1/8″ | Male Straight 4mm R1/8″ |
| PC 04-02 | 4mm | R1/4″ | Male Straight 4mm R1/4″ |
| PC 06-M5 | 6mm | M5 | Male Straight 6mm M5 |
| PC 06-M6 | 6mm | M6 | Male Straight 4mm M6 |
| PC 06-01 | 6mm | R1/8″ | Male Straight 6mm R1/8″ |
| PC 06-02 | 6mm | R1/4″ | Male Straight 6mm R1/4″ |
| PC 06-03 | 6mm | R3/8″ | Male Straight 6mm R3/8″ |
| PC 06-04 | 6mm | R1/2″ | Male Straight 6mm R1/2″ |
| PC 08-01 | 8mm | R1/8″ | Male Straight 8mm R1/8″ |
| PC 08-02 | 8mm | R1/4″ | Male Straight 8mm R1/4″ |
| PC 08-03 | 8mm | R3/8″ | Male Straight 8mm R3/8″ |
| PC 08-04 | 8mm | R1/2″ | Male Straight 8mm R1/2″ |
| PC 10-01 | 10mm | R1/8″ | Male Straight 10mm R1/8″ |
| PC 10-02 | 10mm | R1/4″ | Male Straight 10mm R1/4″ |
| PC 10-03 | 10mm | R3/8″ | Male Straight 10mm R3/8″ |
| PC 10-04 | 10mm | R1/2″ | Male Straight 10mm R1/2″ |
| PC 12-01 | 12mm | R1/8″ | Male Straight 12mm R1/8″ |
| PC 12-02 | 12mm | R1/4″ | Male Straight 12mm R1/4″ |
| PC 12-03 | 12mm | R3/8″ | Male Straight 12mm R3/8″ |
| PC 12-04 | 12mm | R1/2″ | Male Straight 12mm R1/2″ |
| PC 14-03 | 14mm | R3/8″ | Male Straight 14mm R3/8″ |
| PC 14-04 | 14mm | R1/2″ | Male Straight 14mm R1/2″ |
| PC 16-03 | 16mm | R3/8″ | Male Straight 16mm R3/8″ |
| PC 16-04 | 16mm | R1/2″ | Male Straight 16mm R1/2″ |
Inch Size Table
| MODELS | Tube Size | Thread Size | Descriptions |
| PC 1/8-U10 | 1/8″ | 10-32 UNF | Male Straight  1/8″ 10-32 UNF |
| PC 1/8-N01 | 1/8′ | 1/8 NPT | Male Straight  1/8″ 1/8 NPT |
| PC 1/8-N02 | 1/8″ | 1/4 NPT | Male Straight  1/8″ 1/4 NPT |
| PC 5/32-U10 | 5/32″ | 10-32 UNF | Male Straight  5/32″ 10-32 UNF |
| PC 5/32-N01 | 5/32″ | 1/8 NPT | Male Straight 5/32″ 1/8 NPT |
| PC 5/32-N02 | 5/32″ | 1/4 NPT | Male Straight 5/32″ 1/4 NPT |
| PC 3/16-U10 | 3/16 | 10-32 UNF | Male Straight 3/16″ 10-32 UNF |
| PC 3/16-N01 | 3/16 | 1/8 NPT | Male Straight 3/16″ 1/8 NPT |
| PC 3/16-N02 | 3/16 | 1/4 NPT | Male Straight 3/16″ 1/4 NPT |
| PC 3/16-N03 | 3/16 | 3/8 NPT | Male Straight 3/16″ 3/8 NPT |
| PC 1/4-U10 | 1/4″ | 10-32 UNF | Male Straight 1/4″ 10-32UNF |
| PC 1/4-N01 | 1/4″ | 1/8 NPT | Male Straight 1/4″ 1/8 NPT |
| PC 1/4-N02 | 1/4″ | 1/4 NPT | Male Straight 1/4″ 1/4 NPT |
| PC 1/4-N03 | 1/4″ | 3/8 NPT | Male Straight 1/4″ 3/8 NPT |
| PC 1/4-N04 | 1/4″ | 1/2 NPT | Male Straight 1/4″ 1/2 NPT |
| PC 5/16-N01 | 5/16″ | 1/8 NPT | Male Straight 5/16″Â 1/8 NPT |
| PC 5/16-N02 | 5/16″ | 1/4 NPT | Male Straight 5/16″Â 1/4 NPT |
| PC 5/16-N03 | 5/16″ | 3/8 NPT | Male Straight 5/16″Â 3/8 NPT |
| PC 5/16-N04 | 5/16″ | 1/2 NPT | Male Straight 5/16″Â 1/2 NPT |
| PC 3/8-N01 | 3/8″ | 1/8 NPT | Male Straight 3/8″Â 1/8 NPT |
| PC 3/8-N02 | 3/8″ | 1/4 NPT | Male Straight 3/8″Â 1/4 NPT |
| PC 3/8-N03 | 3/8″ | 3/8 NPT | Male Straight  3/8″ 3/8 NPT |
| PC 3/8-N04 | 3/8″ | 1/2 NPT | Male Straight 3/8″Â 1/2 NPT |
| PC 1/2-N01 | 1/2″ | 1/8 NPT | Male Straight 1/2″Â 1/8 NPT |
| PC 1/2-N02 | 1/2″ | 1/4 NPT | Male Straight 1/2″Â 1/4 NPT |
| PC 1/2-N03 | 1/2″ | 3/8 NPT | Male Straight 1/2″Â 3/8 NPT |
| PC 1/2-N04 | 1/2″ | 1/2 NPT | Male Straight 1/2″ 1/2 NPT |
