1/8" 1/4" Size 700 Bar 10000 PSI Super High Pressure Solenoid Valve
AMZ Series 2/2 Way Stainless Steel SS316 Body Material, 1/8" and 1/4" Port Size Miniature type, 700 bar, 70 MPa, 10000 PSI Super high-pressure Ultra High Pressure solenoid valve, anti-corrosion, suitable for washing system, dust cleaning, dust blowing systems, long-lasting, high performance, durable, ultra-high pressure resistance.
Features:
1. AMZ series 2/2 way solenoid valve
2. Port Sizes: 1/8" 1/4"
3. Thread Standard: G, BSP, NPT
4. Materials: Stainless Steel, SS316, SS304
5. Seal options: PTFE PEEK
6. Voltages: 12vDC, 24vDC, 48vDC, 110vAC, 220vAC
7. Quality: Each solenoid valve will be tested individually before shipment, including for functionality and leakage.
2. Port Sizes: 1/8" 1/4"
3. Thread Standard: G, BSP, NPT
4. Materials: Stainless Steel, SS316, SS304
5. Seal options: PTFE PEEK
6. Voltages: 12vDC, 24vDC, 48vDC, 110vAC, 220vAC
7. Quality: Each solenoid valve will be tested individually before shipment, including for functionality and leakage.
8. Normally Closed. N/C Type
Pressure: 700 bar, 70 mPa, 10000PSI
Fluid Media: Air, Water, Liquid Oil.
Fluid Media: Air, Water, Liquid Oil.
| Port Size | Orifice (mm) |
CV Factor |
Operating Pressure Differential(kgf/cm²) (Bar) |
Max. Fluids Temp. (℃) |
Coil
Type |
Coil
Class |
Weight (Kg) |
|
|---|---|---|---|---|---|---|---|---|
| Min. | Max. | |||||||
| 1/8" | 0.5 | 0.02 | 0 | 700 | 80 | DIN | F | 0.87 |
| 1/4" | 0.5 | 0.02 | 0 | 700 | 80 | DIN | F | |
| Coils Model |
Voltage | Power | Electricity | ||
|---|---|---|---|---|---|
| Inrush | Holding | Inrush | Holding | ||
| AM-4101 | AC220V | 130VA | 6.0VA | 590mA | 28mA |
| AM-4102 | AC110V | 95VA | 8.0VA | 900mA | 75mA |
| AM-4106 | DC24V | 45W | 4.5W | 3750mA | 380mA |
