Project Description

MA ISO6432 nini cylinder

MA ISO 6432 Stainless Steel Mini Cylinder

MA series mini-cylinder are designed and produced in accordance with ISO6432 international standards and CETOP RP52P standards. The cylinder bore is from 8mm to 40mm, hereinto the cylinder is with air cushion if the bore sizes below 25mm, which make the cylinder, have a smooth operation and extended product life. As to the bore size above 25mm in normal circumstances there is no buffer, if you need the buffer, please point it out.

Features:
·Front/rear covers machined by All-in CNC machine, high consistency and concentricity
·Japanese anti-dust seal, better sealing performance and dust protection
·Riveted structure for Cylinder barrel and front/rear cover, higher efficiency, better apperance and stronger compression resistance
·Special air cushion design, less impact from piston to front/rear cover
·Caps positioning machine guarantees front and rear caps locate at same horizontal position, easier to install

Supply Chain:
·Japan or Taiwan area seal
·Germany Grease
·Stainless Steel material

MA ISO6432 mini pneumatic cylinder

MA ISO6432 mini pneumatic cylinder

MA ISO6432 mini pneumatic cylinder

MA ISO6432 mini pneumatic cylinder
