The SS316L Cylinder Pressure Regulator combines corrosion-resistant stainless steel construction, a durable brass chrome-plated body, and a versatile 6-port design to deliver stable outlet pressure across a wide range of gases. Featuring a user-friendly handwheel adjustment and built-in inlet filter, it ensures reliable performance for both industrial and medical applications.

Outlet pressure range: 0-10, 0-25, 0-50, 0-100, 0-300psig, 50 bar
Internal component materials:
Valve seat: PCTFE
Diaphragm: 625 alloy,
Filter element: 316L,
Working temperature: -55℃~+300℃,
Leakage rate (helium):
Internal leakage: <1×10-10mbar-l/s,
External leakage: <1×10-10mbar-l/s,
Flow coefficient (Cv): 0.06,
Weight (pressure reducing valve only): 0.9kg,
Body port: 1/4″NPT female thread.

Body material:  SS316 SUS316 SS316L / Chrome plated Brass
Max Inlet Pressure: 300 Bar
Pipe size:1/4″, 3/8″, Customized.
Fluid Media: Compressed air, Gas, Hydrogen, Helium, Nitrogen, etc.

• Stainless Steel Construction
  Made from premium SS316L stainless steel, offering exceptional corrosion resistance and compatibility with multiple gases, including oxygen, CO₂, nitrogen, propane, helium, and LPG.

• Durable Brass Chrome Plating
  The brass chrome-plated body and bonnet enhance durability, protecting against wear and ensuring reliable performance even with demanding high-purity gases (up to Grade 6.0).

• Versatile 6-Port Configuration
  A flexible 6-port design allows seamless integration into diverse systems, delivering unmatched adaptability for different applications.

• Consistent Outlet Pressure
  Engineered for stable outlet pressure, maintaining consistent output under fluctuating inlet conditions—ideal for both industrial processes and medical applications.

• User-Friendly Control
  Features a quick-adjust handwheel for effortless outlet pressure regulation. An integrated inlet filter safeguards internal components, extending service life.
