Cummins Ecofit SCR Urea Tank Heating Solenoid Valve

Cummins Ecofit SCR Urea Tank Heating Solenoid Valve

The Cummins Ecofit SCR Urea Tank Heating Solenoid Valve is a high-performance solution designed for precise control of urea, air, water, and coolant in selective catalytic reduction (SCR) systems. Engineered with a durable brass body and multiple seal material options (NBR, EPDM, FKM), this solenoid valve ensures reliable operation across a wide range of temperatures and pressures. Its compact design, 12 mm orifice, and compatibility with 12VDC and 24VDC coils make it ideal for demanding automotive and industrial applications.

  • Working Mediums: Air, Water, Coolant, Urea

  • Pressure Range: 0 ~ 3 MPa

  • Temperature Range:

    • NBR: -10℃ to +80℃

    • EPDM: -30℃ to +120℃

    • FKM: -30℃ to +150℃

  • Port Size: 1/4”

  • Orifice Size: 12 mm

  • Body Material: Brass

  • Seal Options: NBR, EPDM, FKM

  • Operation: Diaphragm pilot-operated

  • Coil Voltage Options: 12VDC, 24VDC

Product Name Urea Solenoid Valve
Function 2 Way Normally Closed
Operation Diaphragm Pilot Operated
Body Material Brass
Seal Material NBR, FKM, EPDM
Medium Temperature Range NBR (-10 to +80℃)
EPDM (-40 to +120℃)
FKM (-30 to +150℃)
Working Pressure Range 0 to 3 MPa
Port Size 1/4”
Orifice Size 12mm
Voltage 12VDC, 24VDC
